Nominal Diameter 12
Nominal Impedance 4 + 4 Ohms
RMS Power Handling 2000W
MAX Power Handling 4000W
Sensitivity (1w/1m) 87 dB
Frequency Response 20Hz -1.3KHz
Recommended Lo Pass Crossover 80 Hz
Motor:
VC Diameter / 75.6mm
VC Former Material Black Aluminum
Winding Material CCAW
Cone Material Paper
Dust Cap Material Glass Fiber
Surround Material Foam
Basket Material Aluminum
Basket Color/Finish Black
Magnet Material Ferrite
Magnet Weight 306 Oz
Displacement Volume 3.26L
Thiele & Small Parameters
Equivalent Vol Vas 20.738L
Excursion(one way) Xmax 42 mm
Free Air Resonance Fs 41.3 Hz
Mechanical Factor Qms 4.525
Electrical Factor Qes 0.511
Total Factor Qts 0.459
Moving Mass Mms 285.433 g
Compliance Cms 0.026 mm/N
Bl Factor BL 17.166
VC Inductance Le 9.8 mH
Diaphragm Area Sd 433.74 cm²
Dc Resistance Re 3.6 + 3.6 ohms
Efficiency Bandwidth Product EBP 80.8
Measurements
Overall Diameter 12.63" / 321mm
Overall Depth 9.25"/235mm
Front Mount Baffle Cutout 11.1" / 282mm
Mounting Depth 7.87" / 200mm
Motor Diameter 8.89" / 226mm
One year warranty is direct through DS18 only @ 954-924-1213
Dealer MUST contact DS18 direct for any warranty issue for this model. Dealer must request a return authorization, RA#, to return the speaker back to DS18 at the dealers/consumers expense. Once DS18 receives the sub, they will evaluate the speaker to determine if it was a vendor defect or customer abuse
The is NO recone kit available for this model woofer
Specialty is not responsible for any handling of this return or design of the system. We only provide recommendations and the dealer must do their part. It is the dealers responsibility to make sure the proper amplification, wiring, install, etc…is being used and performed
